A shower door sweep is a clear polycarbonate and vinyl strip that snaps on the bottom of your shower door. Some shower door sweeps come with an additional drip rail, which creates a water-resistant seal and sheds water back into the shower. When your frameless shower door is installed, we leave clearance space between the bottom of the door and the floor so that the glass door can swing open without scraping tile. The plastic shower door sweep prevents water from leaking through that clearance space. Sometimes, this sweep is called a "water wipe".



With proper design and installation, frameless showers should not have problems with water leakage, but they are not 100 percent watertight. There are many ways to prevent water leakage around a frameless shower door. When we install your shower enclosure, here are some steps we’ll take to minimize the chance of leakage.

• We will install a shower sweep with a drip rail onto the bottom of your frameless glass shower door. This will tighten up the clearance space under the door and prevent water from escaping the shower.
• We may add a back sweep to the rear of the door. It's a clear vinyl seal mounted with hi-bond tape.
• In some cases, we'll use a doorstop. Our clear polycarbonate doorstops fit over the edge of an adjacent glass panel and have a lip that extends out to catch the frameless shower door preventing it from swinging into the shower. By catching the door, this jam temporarily closes clearance space along the door opening.
• We automatically seal door hinges to give them a protective property as well, but the hinges aren't waterproof.

When your shower is being designed, make sure water does not spray directly at the frameless shower door. Your protective seals improve water tightness, but a glass shower isn't an aquarium.

Replace Your Sweeps Regularly

Over time, sweeps and stops may need replacing just like your car's windshield wipers. If your frameless glass shower suddenly seems less watertight, check your sweeps. You should replace the sweeps when they get too dirty or lose their sealing properties. If you are cleaning your sweeps and notice they are brittle, it’s time to replace them. Generally, this occurs between 1 and 3 years after installation.

Sweeps are very easy to replace. Simply order them from our online store and install them on your own. They snap off the glass and new ones snap easily on.

Clean your shower sweeps when you are cleaning the glass in your shower. If you find these are in need of extra cleaning, snap them off and use a cloth with warm water and a little bleach. Dry your shower sweep and vinyl seal, then just snap them back on again. Please don’t use harsh cleaners on your sweeps, particularly those that are not recommended for glass or hardware. This could cause the failure of the plastic sweeps.

When your shower enclosure is installed, you can, in most cases, use a U-channel or metal clips.

The U-channel is a metal rail that is used to secure glass panels to the floor, ceiling, or wall.

U-Channel Side View

Frameless Shower with U-Channel

U-Channel Close Up on Knee Wall

U-channels reduce the total cost of your frameless shower because the glass sits securely in the channel rather than instead of requiring the drilling and notching of clips. Running U-channels along the bottom and outer edge of your glass shower enclosure does add a "light frame" look to the final product.

While U-channels may be slightly more noticeable than clips, they do not take away from the overall look of your frameless shower. With the right finish, they blend right in to the rest of your hardware and shower, all while adding additional support.

Our U-channels fit 1/2" or 3/8" thick glass.

The U-channels we sell are 3/4" tall. This height offers a stronger "bite" on the glass.

Our U-channels are made from solid aluminum.
